Carbon Offroad UTV & Small Vehicle Winch Recovery Ring
Carbon Offroad UTV & Small Vehicle Winch Recovery Ring
In stock
Fulfilled by Carbon Offroad USA
Billet aluminum recovery ring for compatible ATV, UTV, and small-vehicle winching, with a 3,000kg working load limit and synthetic-rope compatibility up to 12mm. Confirm all rigging ratings before use.
Couldn't load pickup availability
Fast US Standard Shipping &
Easy International Shipping
30-Day Returns
TG Pro
Satisfaction Promise
Trail Grid Pro Tested
- Details
Compact Recovery Ring for Compatible UTV and ATV Winching
The Carbon Offroad UTV & Small Vehicle Winch Recovery Ring provides a compact alternative to a traditional steel snatch block for appropriately matched lightweight-vehicle recoveries. Machined from solid billet 6061-T6 aluminum, it has no moving parts, bearings, or pulleys to seize or clog with mud.
Use it in an approved double-line configuration with compatible synthetic winch rope to obtain mechanical advantage. Its small dimensions make it easy to pack with your UTV or ATV recovery equipment.
Specifications
- Working load limit: 3,000kg (6,614lb).
- Material: solid billet 6061-T6 aluminum.
- Outer diameter: 58mm (2.3 inches).
- Inner diameter: 30mm (1.2 inches).
- Width: 22mm (0.9 inch).
- Maximum rope diameter: 12mm (0.5 inch), synthetic rope.
Compatibility and Use
Designed for compatible UTVs, ATVs, and lightweight vehicles, not universal full-size 4x4 recovery. Confirm rope compatibility, connector suitability, and all equipment and anchor ratings. Mechanical advantage depends on rigging and can increase loads elsewhere in the system. Follow the manufacturer's instructions and working load limit, inspect before use, and maintain safe clearances.
