Toyota 4Runner Morimoto XB LED Mirror Light Install Guide

Upgrading the mirror turn signals on your 2014+ Toyota 4Runner to the Morimoto XB LED Sequential Mirror Light has many benefits. First of all, it is going to improve the overall aesthetics of your vehicle. Not to say the standard factory installed lights aren’t great, but let’s face it, the Morimoto XB LED's are next level. And equally important, the Morimoto XB LED Mirror Lights will make your Toyota 4Runner more visible to the people you are sharing the road with, therefore decreasing potential collisions.

Toyota-4runner-morimoto-xb-led-mirror-light

Morimoto XB LED Sequential Mirror Lights

Morimoto XB LED Mirror Light Back

Morimoto XB LED Mirror Light

Install your Morimoto XB LED Tail Lights

Here is a simple and easy breakdown of how to install your new Morimoto XB LED Sequential Mirror Lights. If you're more of a visual learner, check out our complete installation video here.

Step 1

First of all, check the packaging and make sure it hasn’t been damaged; then check out the parts to make sure they are intact and ready to go. You will have:

2x Mirror Light Assemblies (1- Drivers Side, 1- Passengers Side)

Tools Needed:

Panel Removal Tool
Philips Head Screwdriver
Small Flat Head Screwdriver

Step 2

Read all the 4Runner installation directions and read this important message from the manufacturer.

Step 3

Remove upper mirror cover by placing firm pressure on the cap away from the mirror.

Step 4

Remove two Philips head screws.

Step 5

Remove wires from retaining hook.

Step 6

Push in on the mirror trim to release end closest to window.

Step 7

Release tabs on trim using panel tools and gently pressure.

Step 8

Remove puddle light, if equipped by twisting.

Step 9

Depress tab on top light with panel tool to release the light itself.

Step 10

Disconnect wiring harness.

Step 11

Install new Morimoto light, starting with connecting the wiring harness.

Step 12

Push light into place, if it doesn't fit you may have the two backwards (There is a driver side and passenger side, they are NOT interchangeable).

Step 13

Reinstall puddle light, if equipped.

Step 14

Reinstall lower mirror trim, ensure all edges are lined up and secured.

Step 15

Re-install two Philips head screws.

Step 16

Re-install upper mirror cover.

Step 17

Test functionality.

Congratulations on installing your new Morimoto XB LED Sequential Mirror Lights!

Step back and take a look at those beauties! The Morimoto XB LED Sequential Mirror Lights not only add to your vehicle’s overall aesthetic (a.k.a. coolness) but now you will be safer on and off the road.
